Features
- Series MTH appliances have In / Out wiring terminations that accept (2) two #12 to #18 American Wire Gauge (AWG) wires at each terminal
- Inputs are polarized for compatibility with standard reverse polarity-type supervision
- Strobes can be synchronized using the Siemens DSC sync modules, FS-250 panel, XLS panel, MXL panel, or PAD-3 power supply with built-in sync protocol
- MTH Strobe models are available with Siemens MC multi-Candela strobes with field-selectable Candela settings at 15/30/75/110cd
- One alarm appliance with (8) eight selective signals to provide superior sound penetration for various ambient and wall conditions with two field-selectable, sound-output levels
- Audible and strobe can operate from a single NAC circuit or from separate NAC circuits with any of the (8) eight audible sounds
- No additional trim plate required for flush mounting
- Code-3 Horn and Tone meet ANSI / NFPA temporal pattern for standard, emergency-evacuation signaling
- UL Listed & ULC Listed; FM, CSFM & NYMEA Approved
- Complies with OSHA 29, Part 1910.165
